5.164 L_TbCurveAny - Characteristic function
This FB represents a characteristic/curve function y = f(x). Here, the input signal corresponds to the
x axis and the output signal corresponds to the y axis.
• The characteristic can consist of up to 127 points which are defined by parameters.
• Between the points a linear interpolation takes place.
• The characteristic can be entered over the entire value range and can also be created symmet-
rically to the y axis or zero point by selecting the corresponding characteristic mode in C04045.
Inputs
Outputs
Parameters
Function library: LenzeToolbox FB is available as of library V02.06.xx.xx!
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
dnIn
DINT
Input signal
Identifier/data type Value/meaning
dnOut
DINT
Output signal
Parameter Possible settings Info
C04045 Characteristic mode
0 Entire range Lenze setting
1 Symmetrically to the y axis
2 Symmetrically to the zero point
