5 Function blocks
5.53 L_DcSpeed_sToNorm_n - signal converter
240
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.53 L_DcSpeed_sToNorm_n - signal converter
This FB uses the transmitted machine parameters and converts a 32-bit speed signal into a scaled
32-bit signal.
Inputs
Outputs
Function library: LenzeDataConversion
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
dnIn_s
DINT
Input signal in [rpm]
• 15000 rpm ≡ 2 26 ≡ 67108864
AxisData Machine parameters
• For accepting the machine parameters of the drive/motor, connect this input
with the output DI_AxisData of the SB LS_DriveInterface.
• The machine parameters of a master drive can be displayed with the
FB L_SdSetAxisData . In this case, the FB output AxisData must be connected to
this input. ( 510)
Identifier/data type Value/meaning
dnOut_n
DINT
Output signal in [%]
• 100 % ≡ 2 30 ≡ 1073741824
GQ2XWBQ GQ,QBV
$[LV'DWD
/B'F6SHHGBV7R1RUPBQ
>USP@ %LW >@ %LW
