5 Function blocks
5.75 L_DevSMControlDecoder - control signals from the safety module
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3 bSafelyLimitedSpeed1 Safely limited speed 1 (SLS1)
4 bSafelyLimitedSpeed2 Safely limited speed 2 (SLS2)
5 bSafelyLimitedSpeed3 Safely limited speed 3 (SLS3)
6 bSafelyLimitedSpeed4 Safely limited speed 4 (SLS4)
7 bSafeDirectionPos Safe positive direction of rotation (SDIp)
8 bSafeDirectionNeg Safe negative direction of rotation (SDIn)
9 bSafeEnablingSwitch Safe enable switch (ES)
10 bSafelyLimitedIncrements Safely limited increments (SLI)
11 bOperationModeSelector Safe operation mode selector (OMS)
12 bSafelyLimitedPosition1 Safely limited position 1 (SLP1)
13 bSafelyLimitedPosition2 Safely limited position 2 (SLP2)
14 bSafelyLimitedPosition3 Safely limited position 3 (SLP3)
15 bSafelyLimitedPosition4 Safely limited position 4 (SLP4)
16 bSafeOperatingStop Safe operating stop (SOS)
23 bSafeStopEmergency Emergency stop (SSE)
29 bSpecialOperationActive Special operation is active
Bit* Identifier Requested/active safety functions with TRUE
* Relating to the input signal dwControl.
