5 Function blocks
5.196 L_TbSampleHold - sample & hold (for "DINT" data type)
618
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.196 L_TbSampleHold - sample & hold (for "DINT" data type)
This FB can save a signal from the "DINT" data type.
• The stored value is also available after mains disconnection.
Inputs
Outputs
Behaviour when switching the mains
The value loaded last is stored permanently when the supply voltage is switched off and reloaded
after the mains is switched on again.
• In order that the stored value is not immediately overwritten by the current input signal at dnIn
after switching on the mains again, bLoad must be set to FALSE when the mains is switched on
again.
Function library: LenzeToolbox
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Required retain memory: 32 bytes
Identifier/data type Information/possible settings
dnIn
DINT
Input signal
bLoad
BOOL
Saving of input signal
FALSE The value valid last at dnIn is stored and output to dnOut. A signal
change at dnIn does not change dnOut.
TRUE dnIn is output at the output dnOut.
Identifier/data type Value/meaning
dnOut
DINT
Output signal
GQ2XW
E/RDG
GQ,Q
/B7E6DPSOH+ROG
6 +
