Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C05122
Positive speed
19453
4BFD
S
1
INTEGER_32
10000
C05123
Negative speed
19452
4BFC
S
1
INTEGER_32
10000
C05124
Ramp: Acceleration
19451
4BFB
S
1
UNSIGNED_32
1000
C05125
Ramp: Deceleration
19450
4BFA
S
1
UNSIGNED_32
1000
C05126
Ramp: Motor potentiometer off
19449
4BF9
S
1
UNSIGNED_32
1000
C05127
Speed at the output
19448
4BF8
S
1
INTEGER_32
10000
C05128
Speed unit
19447
4BF7
S
1
VISIBLE_STRING
1
C05129
Reference speed
19446
4BF6
S
1
INTEGER_32
10000
C05050
Positioning mode
19525
4C45
S
1
UNSIGNED_32
1
C05051
Mode after deactivation
19524
4C44
S
1
UNSIGNED_32
1
C05052
Unit
19523
4C43
A
2
VISIBLE_STRING
1
C05053
Speeds
19522
4C42
A
2
INTEGER_32
10000
C05054
Reference speed
19521
4C41
S
1
INTEGER_32
10000
C05056
Ramps
19519
4C3F
A
3
INTEGER_32
1000
C05065
Speed at the output
19510
4C36
S
1
INTEGER_32
10000
C05067
Position at the output
19508
4C34
S
1
INTEGER_32
10000
C05069
Set position reached
19506
4C32
S
1
UNSIGNED_8
1
C05034
Status
19541
4C55
S
1
INTEGER_32
1
C05035
Unit
19540
4C54
A
2
VISIBLE_STRING
1
C05036
Speed at the output
19539
4C53
S
1
INTEGER_32
10000
C05037
Master speed
19538
4C52
S
1
INTEGER_32
10000
C05041
Measured cycle
19534
4C4E
S
1
INTEGER_32
10000
C05042
Measured TP deviation
19533
4C4D
S
1
INTEGER_32
10000
C05043
Position at the output
19532
4C4C
S
1
INTEGER_32
10000
C05048
TP: Deviation detected
19527
4C47
S
1
UNSIGNED_8
1
C05049
Cycle start
19526
4C46
S
1
UNSIGNED_8
1
C05090
Coupling measuring systems X and Y
19485
4C1D
S
1
UNSIGNED_32
1
C05091
User-defined units
19484
4C1C
A
2
VISIBLE_STRING
1
C05092
Coupling factors
19483
4C1B
A
2
INTEGER_32
10000
C05093
Cycles
19482
4C1A
A
2
INTEGER_32
10000
C05094
Position X at the input
19481
4C19
S
1
INTEGER_32
10000
C05095
Trimming X
19480
4C18
S
1
INTEGER_32
10000
C05096
Speed X at the output
19479
4C17
S
1
INTEGER_32
10000
C05097
Speed Y at the output
19478
4C16
S
1
INTEGER_32
10000
C05098
Position X at the output
19477
4C15
S
1
INTEGER_32
10000
C05099
Status
19476
4C14
S
1
INTEGER_32
1
C05142
Status
19433
4BE9
S
1
INTEGER_32
1
C05143
Unit
19432
4BE8
A
2
VISIBLE_STRING
1
C05144
Reference speed
19431
4BE7
S
1
INTEGER_32
10000
C05147
Correction speed at the input
19428
4BE4
S
1
INTEGER_32
10000
C05148
Speed at the input
19427
4BE3
S
1
INTEGER_32
10000
C05149
Speed at the output
19426
4BE2
S
1
INTEGER_32
10000
C05150
Set position at the output
19425
4BE1
S
1
INTEGER_32
10000
C05151
Actual position at the output
19424
4BE0
S
1
INTEGER_32
10000
C05152
Following error
19423
4BDF
S
1
INTEGER_32
10000
C05153
Measured TP deviation
19422
4BDE
S
1
INTEGER_32
10000
Code
Name
Index
Data
Access
dec
hex
DS
DA
DT
Factor
R
W
CINH
