4 Short overview
4.14 FB reference list - 9300 servo inverter
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.14 FB reference list - 9300 servo inverter
The following reference list shall assist you in finding the correct function block to simulate a func-
tion known from the 9300 servo inverter.
Function block for 9300 servo inverter Function block for 9400 Servo Drives
Name Description Name Description
ABS Absolute value generator L_TbAbs Absolute value generation
ADD Addition block L_TbAdd Addition without limitation
L_TbAddLim Addition with limitation
L_TbAddSubLim Addition and subtraction with limi-
tation
AIF-IN Fieldbus - -
AIF-OUT Fieldbus - -
AIN Analog inputs LS_AnalogInput SB Analog inputs
AND AND L_TbAnd AND (2 inputs)
L_Tb5And AND (5 inputs)
ANEG Analog inverter L_TbNeg Sign inversion
AOUT Analog outputs LS_AnalogOutput SB Analog outputs
ARIT Arithmetic block L_TbAdd Addition without limitation
L_TbAddLim Addition with limitation
L_TbAddSubLim Addition and subtraction with limi-
tation
L_TbDiv Division with remainder
L_TbDiv_n Division divisor selected as scaled si-
gnal [%]
L_TbMul Multiplication without limitation
L_TbMul_n Multiplication with the multipli-
cand selected as scaled signal [%]
L_TbMulLim Multiplication with limitation
L_TbSub Subtraction without limitation
L_TbSubLim Subtraction with limitation
ARITPH 32 bit arithmetic block L_TbAdd Addition without limitation
L_TbAddLim Addition with limitation
L_TbAddSubLim Addition and subtraction with limi-
tation
L_TbDiv Division with remainder
L_TbDiv_n Division divisor selected as scaled si-
gnal [%]
L_TbMul Multiplication without limitation
L_TbMul_n Multiplication with the multipli-
cand selected as scaled signal [%]
L_TbMulLim Multiplication with limitation
L_TbSub Subtraction without limitation
L_TbSubLim Subtraction with limitation
ASW Analog change-over switch L_Tb8Select 1-from-8-selector
L_TbSelect Selector
BRK Holding brake control LS_Brake SB Basic function "Brake control"
CAN-IN System bus Network configuration in the »Engineer«, interconnection via ports in the
machine application.
CAN-OUT
CMP
Comparator L_TbCompare Comparison
L_TbCompare_n Comparison (scaled)
CONV Conversion L_TbGainLim Gain with limitation
L_TbNormalize Signal scaling
CONVPHA 32 bit conversion - -
CONVPHPH 32 bit conversion - -
