5 Function blocks
5.136 L_SdSetAxisData - machine parameters
510
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.136 L_SdSetAxisData - machine parameters
This FB serves to indicate the machine parameters of a master drive. The FB processes the machine
parameters which you define with the physical units of the machine via parameters for the internal
representation.
• The FB outputs a pointer to the data structure with the prepared machine parameters at the
output AxisData.
• To transmit the machine parameters to another FB, which requires these data for internal cal-
culations, the output AxisData must simply be connected to the input of the same name of the
corresponding FB.
Outputs
Function library: LenzeServoDrive
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Value/meaning
AxisData Machine parameters
• Pointer to a data structure the elements of which contain the machine parame-
ters in the internal measuring system.
• Via this "interface" the machine parameters can be provided for other FBs which
require these data for internal calculations.
dnCycleLength_p
DINT
As of library V02.05.xx.xx
Cycle in [increments]
• C04248 indicates the cycle in the real unit of the machine.
$[LV'DWD
/B6G6HW$[LV'DWD
& *HDUER[IDFWRUQXPHUDWRU
& 8VHUGHILQHGSDWKXQLW
& 7LPHXQLW
& 5HVROXWLRQRIDQHQFRGHUUHYROXWLRQ
GQ&\FOH/HQJWKBS
& 5HIHUHQFHVSHHG
& 7UDYHUVLQJUDQJH
& 5HVROXWLRQRIDXQLW
& 5HVXOWLQJJHDUER[IDFWRU
0DFKLQHSDUDPHWHUV
& *HDUER[IDFWRUGHQRPLQDWRU
& 3DWKXQLW
& )HHGFRQVWDQW
& &\FOH
