Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C05525
Cam type
19050
4A6A
S
1
INTEGER_32
1
C05526
Input position
19049
4A69
S
1
INTEGER_32
10000
C05527
Track number
19048
4A68
S
1
INTEGER_32
1
C05528
Cycle
19047
4A67
S
1
INTEGER_32
10000
C05529
Status
19046
4A66
S
1
INTEGER_32
1
C05540
X position unit
19035
4A5B
A
2
VISIBLE_STRING
1
C05541
Y position unit
19034
4A5A
A
2
VISIBLE_STRING
1
C05547
Input value
19028
4A54
S
1
INTEGER_32
1
C05548
Output value
19027
4A53
S
1
INTEGER_32
1
C05549
Status
19026
4A52
S
1
INTEGER_32
1
C05400
Position unit
19175
4AE7
A
5
VISIBLE_STRING
1
C05401
Designation of the axis
19174
4AE6
S
1
INTEGER_32
1
C05406
Gearbox ratio - numerator
19169
4AE1
S
1
INTEGER_32
1
C05407
Gearbox ratio - denominator
19168
4AE0
S
1
INTEGER_32
1
C05408
Resulting gearbox factor
19167
4ADF
S
1
INTEGER_32
10000
C05409
Feed constant
19166
4ADE
S
1
INTEGER_32
10000
C05410
Measuring system
19165
4ADD
S
1
INTEGER_32
1
C05411
Resolution of a user unit
19164
4ADC
S
1
INTEGER_32
10000
C05412
Resolution of encoder revolution
19163
4ADB
S
1
INTEGER_32
1
C05413
Cycle
19162
4ADA
S
1
INTEGER_32
10000
C05414
Reference speed
19161
4AD9
S
1
INTEGER_32
10000
C05415
Maximum machine speed
19160
4AD8
S
1
INTEGER_32
10000
C05419
Status
19156
4AD4
S
1
INTEGER_32
1
C05530
X position unit
19045
4A65
A
4
VISIBLE_STRING
1
C05534
Track number
19041
4A61
S
1
INTEGER_32
1
C05536
X coordinate of the position marker
19039
4A5F
A
4
INTEGER_32
10000
C05537
Y coordinate of the position marker
19038
4A5E
A
4
INTEGER_32
10000
C05539
Status
19036
4A5C
S
1
INTEGER_32
1
C05500
X position unit
19075
4A83
A
4
VISIBLE_STRING
1
C05501
Y position unit
19074
4A82
A
4
VISIBLE_STRING
1
C05502
X reference speed
19073
4A81
S
1
INTEGER_32
10000
C05505
Track switch-over mode
19070
4A7E
S
1
INTEGER_32
1
C05506
Dynamisation time
19069
4A7D
S
1
INTEGER_32
1000
C05507
Feed forward gain
19068
4A7C
S
1
INTEGER_32
100
C05510
Input position X
19065
4A79
S
1
INTEGER_32
10000
C05511
Offset feedforward control X
19064
4A78
S
1
INTEGER_32
10000
C05514
Output position Y
19061
4A75
S
1
INTEGER_32
10000
C05515
Initial speed Y
19060
4A74
S
1
INTEGER_32
10000
C05516
Output acceleration Y
19059
4A73
S
1
INTEGER_32
10000
C05517
Feed length Y
19058
4A72
S
1
INTEGER_32
10000
C05518
Cycle X
19057
4A71
S
1
INTEGER_32
10000
C05519
Status
19056
4A70
S
1
INTEGER_32
1
C05560
Position unit
19015
4A47
S
1
VISIBLE_STRING
1
C05561
Cam type
19014
4A46
S
1
INTEGER_32
1
C05564
Switch-on position
19011
4A43
A
8
INTEGER_32
10000
C05565
Switch-off position
19010
4A42
A
8
INTEGER_32
10000
Code
Name
Index
Data
Access
dec
hex
DS
DA
DT
Factor
R
W
CINH
