4 Short overview
4.13 FB reference list - 9300 Servo PLC
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.13 FB reference list - 9300 Servo PLC
The following reference list shall assist you in finding the correct function block to simulate a func-
tion known from 9300 servo PLC.
Function block for 9300 servo PLC Function block for 9400 Servo Drives
Name Description Function library Name Description
L_32BitTransferDINT Data-consistent copying of
a DINT variable
Lenze32BitTransferDrv - -
L_32BitTransferDWORD Data-consistent copying of
a DWORD variable
Lenze32BitTransferDrv - -
L_8200CtrlWord Control word for the fre-
quency inverter
Lenze8200Drive - -
L_8200DataControl Process data exchange with
frequency inverter
Lenze8200Drive - -
L_8200Initialization Initialise frequency inverter Lenze8200Drive - -
L_8200Parameter Initialise codes Lenze8200Drive - -
L_8200StatusWord Status word of frequency in-
verters
Lenze8200Drive - -
L_ABS Absolute value generation LenzeDrive.lib L_TbAbs Absolute value generation
L_ADD Addition LenzeDrive.lib L_TbAdd Addition without limitation
L_TbAddLim Addition with limitation
L_AifParMapClose* Deactivate code mapping LenzeAifParMapDrv - -
L_AifParMapInit* Configure code mapping LenzeAifParMapDrv - -
L_AifParMapOpen* Activate code mapping LenzeAifParMapDrv - -
L_AIN Input gain & offset LenzeDrive.lib LS_AnalogInput SB Analog inputs
L_AND AND LenzeDrive.lib L_TbAnd AND (2 inputs)
L_Tb5And AND (5 inputs)
L_ANEG Inversion LenzeDrive.lib L_TbNeg Negation
L_TbNegSel Negation (optional)
L_AOUT Output gain & offset LenzeDrive.lib L_TbGainLim Gain with limitation
L_TbAdd Addition without limitation
L_TbAddLim Addition with limitation
L_TbAddSubLim Addition and subtraction
with limitation
L_ARIT Arithmetic LenzeDrive.lib L_TbAdd Addition without limitation
L_TbAddLim Addition with limitation
L_TbAddSubLim Addition and subtraction
with limitation
L_TbDiv Division with remainder
L_TbDiv_n Division divisor selected as
scaled signal [%]
L_TbMul Multiplication without limi-
tation
L_TbMul_n Multiplication with the mul-
tiplicand selected as scaled
signal [%]
L_TbMulLim Multiplication with limitati-
on
L_TbSub Subtraction without limita-
tion
L_TbSubLim Subtraction with limitation
* Function (no function block)
