3.4.2
Insert/delete objects
Objects can be inserted in the interconnection via the FB Editor toolbar and the context menu of the
drawing area. The following subchapters provide detailed information on how to insert/delete the
different objects.
Tip!
Use the context menu of the drawing area to insert a function block, system block, port
block or comment directly to the current position of the mouse pointer in the drawing area.
If you insert an object via the corresponding icon in the FB Editor toolbar, the object is al-
ways placed at the top left corner in the drawing area.
As of the »Engineer« V2.9, interconnection elements cannot only be copied within the
same interconnection but also across all devices within the same project, as long as the de-
vices stem from the same product family.
Copying interconnection elements (across all
Icon
Function
Inserting a function block ( 53)
Inserting a system block ( 56)
Creating/inserting a variable ( 59)
Configuring/inserting a user code ( 62)
