5 Function blocks
5.96 L_LdStateDecoder - LineDrive status signals
358
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.96 L_LdStateDecoder - LineDrive status signals
This FB decodes the status output signal dnState of an FB from the function library "LenzeLineDri-
ve.lib" into individual boolean status signals for further use in the FB interconnection.
• The functionality corresponds to a converter "DINTBOOL", but the boolean outputs of this FB
have the same names according to their meaning.
Inputs
Function library: LenzeLineDrive
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
dnState
DINT
Input for the bit-coded status signal of an FB from the function library "LenzeLineDri-
ve.lib".
• Connect this input with the output of the same name of the corresponding FB.
/B/G6WDWH'HFRGHU
GQ6WDWH
E$FWLYH
E'RQH
E$FF'HF
E:DUQ3RV'LII
E1HJDWLYH'LU
E&OXWFK&ORVH
E:DLW&ORVH
E=HUR3RV
E/LPLW
E(UURU
E(UU6WDUW3RV
E(UU([W0DVWHU
E(UU&\FOH/HQJWK
E(UU0D[6SHHG
E(UU733RV
E(UU,QSXW
E(UU&\FOH/HQJWK<
E(UU$[LV'DWD
E&\FOH
E$XWRPDWLF
E6WRS,QVWDQW
E0DQXDO-RJ
E,QWHUQDO6SHHG
E(UU3RV([W0DVWHU
/LQHGULYHVWDWHVLJQDOV
E,QLW
E5HVHUYH
E5HVHUYH
E5HVHUYH
E,QLW6HW&\FOH
E,QLW$FW&\FOH
E+DQGZKHHO
E5HVHUYH
