5 Function blocks
5.13 L_Dc2WordsToDWord- type converter
198
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.13 L_Dc2WordsToDWord- type converter
This FB converts two input values of type "WORD" into an output value of type "DWORD".
Inputs
Outputs
Function library: LenzeDataConversion
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
wInput1
WORD
Input value 1 ≡ bit 0 ... bit 15 of dwOutput
wInput2
WORD
Input value 2 ≡ bit 16 ... bit 31 of dwOutput
Identifier/data type Value/meaning
dwOutput
DWORD
Value of type "double word" according to the transmitted input values
/B'F:RUGV7R':RUG
Z,QSXW
Z,QSXW
GZ2XWSXW
