Lenze E94A - Manual (Page 413)

Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
413
5 Function blocks
5.111 L_PosPositionerTable - profile data record management
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Touch probe configuration
The touch probe channel for positioning with touch probe detection can be selected in the »Engi-
neer« via the parameter dialog of the FB L_PositionerTable.
• Go to the parameter dialog of the FB L_PositionerTable and press the Setting up touch probe
button to open the Setting up touch probe dialog box and select the desired setting for the cor-
responding profile.
• The setting selected in this parameterisation dialog has a direct effect on the setting of C04721/
1...75 ("touch probe configuration") and vice versa.
• For a direct setting of C04721/1...75 (e.g. via keypad) the following table lists the corresponding
decimal values for all possible configurations.
• Example: For the selection of the touch probe channel "DIGIN 8" and the response to only one
positive edge, the decimal value "16384" must be set in C04721.
5.111.6 Monitoring for counter overflow
This function extension will be available from library V2.02!
If the machine parameters transferred to the FB via the AxisData input are changed afterwards (e.g.
the gearbox factors), this may cause a counter overflow when the speed, acceleration, and position
values defined via parameters are converted from the real unit to the internal unit.
The FB causes a corresponding error message in case of an internal counter overflow due to a chan-
ged measuring system:
Selection
Touch probe channel
Touch probe response
Positive edge
Negative edge Both edges
DIGIN 1 1 2 3
DIGIN 2 4 8 12
DIGIN 3 16 32 48
DIGIN 4 64 128 192
DIGIN 5 256 512 768
DIGIN 6 1024 2048 3072
DIGIN 7 4096 8192 12288
DIGIN 8 16384 32768 49152
Motor encoder zero pulse 65536
Load encoder zero pulse 262144
DFIN zero pulse 1048576
DFOUT zero pulse 4194304
Error number Error message in the logbook Response
61736961 0x3AE0801 L_PosPositionerTable:int.pos. overflow (LS_DriveInterface) Error
61737217 0x3AE0901 L_PosPositionerTable:int.pos. overflow (L_SdSetAxisData) Error
61735937 0x3AE0401 L_PosPositionerTable:int.speed overflow (LS_DriveInterface) Error
61736193 0x3AE0501 L_PosPositionerTable:int.speed overflow (L_SdSetAxisData) Error
61735425 0x3AE0201 L_PosPositionerTable:int.accel. overflow (LS_DriveInterface) Error
61735681 0x3AE0301 L_PosPositionerTable:int.accel. overflow (L_SdSetAxisData) Error
