5 Function blocks
5.5 L_CamPosMarker - reading out position marks from cam data
160
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C05534 0 2147483647 Number of the position data track
• Display of the dnTrackNumber in-
put signal.
C05536/1...4 -214748.3647 Unit 214748.3647 Position marker 0 ... 3: x position
• Display of the x positions in the
real unit of the machine.
C05536/5...8
From library V01.02.xx.xx
-214748.3647 Unit 214748.3647 Position marker 4 ... 7: x position
• Display of the x positions in the
real unit of the machine.
C05537/1...4 -214748.3647 Unit 214748.3647 Position marker 0 ... 3: y position
• Display of the y positions in the
real unit of the machine.
C05537/5...8
From library V01.02.xx.xx
-214748.3647 Unit 214748.3647 Position marker 4 ... 7: y position
• Display of the y positions in the
real unit of the machine.
C05539 Error messages: Status (bit coded)
• Bits that are not itemised are re-
served for future extensions.
• Bit 31 is the default setting if one
or more other error bits (bit 16 ...
30) are set.
bits22 Invalid X axis data structure
bits23 Invalid Y axis data structure
bits25 Invalid data track number
bits31 General error
Parameter Possible settings Information
