5 Function blocks
5.93 L_LdMPot - master value adjustment
338
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Outputs
Parameter
Identifier/data type Value/meaning
bBusy
BOOL
Status signal "Master value adjustment is active"
FALSE Master value adjustment is deactivated.
• Output dnSpeedOut_s = "0".
TRUE Master value adjustment is activated.
• Output dnSpeedOut_s ≠ "0".
dnSpeedOut_s
DINT
Master speed output in [rpm]
• C05127 indicates the master speed in the real unit of the machine.
Parameter Possible settings Information
C05122 -214000.0000 Unit/t 214000.0000 Positive speed
• Initialisation: 1.0000 unit/t
C05123 -214000.0000 Unit/t 214000.0000 Negative speed
• Initialisation: 1.0000 unit/t
C05124 0.001 s 130.000 Ramp: Acceleration
• Initialisation: 1.000 s
C05125 0.001 s 130.000 Ramp: Deceleration
• Initialisation: 1.000 s
C05126 0.001 s 130.000 Ramp: Motor potentiometer off
• Initialisation: 1.000 s
C05127 -214748.3647 Unit 214748.3647 Speed at the output
• Read only
• Calculated from the speed signal
dnSpeedOut_s.
C05128
As of library V02.02.xx.xx
String of digits Speed unit
• Read only
C05129
As of library V02.02.xx.xx
-214748.3647 Unit/t 214748.3647 Reference speed
• Read only
• For input orientation for speed
entries.
