5.4 L_CamGetAxisData - reading out machine parameters from cam data
156
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Outputs
Parameters
Identifier/data type Value/meaning
AxisData Machine parameters of the axis selected
• In order to transfer the machine parameters to another FB, this output just has to
be connected to the input AxisData of the corresponding FBs.
bError
BOOL
"Error" status
TRUE An error has occurred (group signal).
• For details see display parameters C05419.
dnCycleLength_p
DINT
From library V01.01.xx.xx
Cycle in [increments]
• C05413 indicates the cycle in the real unit of the machine.

Note!
Observe that the index of the codes listed in the following only applies to the first in-
stance!
Parameter Possible settings Info
C05400/1 Character string Position unit
• Read only
C05400/2 Character string Speed unit
• Read only
C05400/3 Character string Acceleration unit
• Read only
C05400/4 Character string Time unit
• Read only
C05400/5 Character string Axis designation
• Read only
C05401 0 65535 Axis number
• Display of the currently valid axis
number from the axis data.
C05406 1 2147483647 Gearbox factor numerator
• Read only
C05407 1 2147483647 Gearbox factor denominator
• Read only
C05408 0.0000 214748.3647 Resulting gearbox factor
• Read only
C05409 0.0001 Unit 214748.3647 Feed constant
• Read only
C05410 Measuring system
• Read only
0 Unlimited
1 Limited
2 Modulo
C05411 0.0000 Incr./unit 214748.3647 Resolution - application unit
• Read only
C05412 10 Bit 24 Resolution of encoder revolution
• Read only
