5 Function blocks
5.114 L_PosSequencer - sequence control
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.114.3.8 Action type "Counter setting"
10 actions of type "Counter setting" are available for setting one of the 10 available counters to a
certain starting value.
• The 10 actions of type "Counter setting" are not permanently assigned to the 10 counters.
• You can use, for instance, an action of type "Counter setting" to set a counter to a value and later
you can set the same counter with another action of type "Counter setting" to another value.
Action call (entry in the sequence table)
with action number xxx = 001 ... 010
Parameter
The available actions 1 ... 10 are indicated via the subcodes 1 ... 10.
Parameter Possible settings Information
C04580/1...10 Counter selection
0 "Counter setting" is deactivated.
1 Counter 1
... ...
10 Counter 10
C04581/1...10 -2147483647 2147483647 New counter content
C04582/1...10 -2147483647 2147483647 Current counter content
• Read only
0
Set
0 0
8 x x x
