3 Working with the FB editor
3.4 Creating/reconfiguring the interconnection
66
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Insert a user code into the interconnection
A user code contained in the list field can be inserted exactly once with input (for value assignment)
into the interconnection and as often as required with one output (for read access).

How to insert a user code into the interconnection:
1. Go to the Assign User Code dialog box and select the user code to be inserted in the list field.
2. Press the Insert (with output) or Insert (with input) button to insert a user code with input
or output into the interconnection.
Context menu for user code
If you right-click on the header of a user code, a context menu opens via which you can execute the
following functions in addition to the general processing functions (Copy, Insert, Delete):
Related topics:
 Deleting objects that are no longer required ( 70)
 Deleting variables and user codes from the application ( 71)
 Arranging objects in the drawing area ( 73)
 Creating/deleting connections ( 74)
Command Function
Changing a value Display/change value of the user code.
