5 Function blocks
5.158 L_TbAddSubLim - addition and subtraction with limitation
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.158 L_TbAddSubLim - addition and subtraction with limitation
This FB carries out an addition with subsequent subtraction and limitation.
• The value output to output dnOut is internally limited to ±2 31 -1.
• The bLimitActive output displays if a limitation is active.
Inputs
Outputs
Function library: LenzeToolbox FB is available as of library V02.04.xx.xx!
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
dnIn
DINT
Input value
dnAdd
DINT
Value that is added to the input value.
dnSub
DINT
Value that is subtracted from the input value.
Identifier/data type Value/meaning
dnOut
DINT
Result of the calculation
• Internally limited to ±2 31 -1
bLimitActive
BOOL
Status signal "Limitation active"
TRUE The output signal is limited.
/B7E$GG6XE/LP
GQ2XW
E/LPLW$FWLYH
GQ,Q
GQ$GG
DEF
GQ6XE
