5 Function blocks
5.82 L_EsStretchIntegrate - synchronously stretching/compressing the master value
306
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C05294 -2147483647 Unit/t 2147483647 Input speed
• Display of the dnSpeedIn_s input
signal.
C05295 -214748.3647 214748.3647 Effective stretch factor
C05296 -214748.3647 Unit 214748.3647 Starting position
• Display of the dnStartPos_p input
signal in the real unit of the ma-
chine.
C05297 -214748.3647 Unit 214748.3647 Master position
• Display of the dnPosOut_p output
signal in the real unit of the ma-
chine.
C05298 -214748.3647 Unit/t 214748.3647 Master speed
• Display of the dnSpeedOut_s out-
put signal in the real unit of the
machine.
C05299 Status messages: Status (bit coded)
• Bits that are not itemised are re-
served for future extensions.
• The bError error output will only
be set to TRUE if an error message
(bit 16 ... 31) is issued.
• Bit 31 is the default setting if one
or more other error bits (bit 16 ...
30) are set.
bits10 Zero crossing active
Error messages:
bit16 Position is beyond the cycle
bits17 Initial speed too high
bits21 Position jump is too big
bits23 Invalid axis data structure
bits31 General error
Parameter Possible settings Information
