5 Function blocks
5.114 L_PosSequencer - sequence control
444
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.114.3.5 Action type "Variable branching"
For variable branches (jumps) 5 actions of type "Variable branching" are available.
• The branch to one of 20 possible steps is executed depending on the input signal dwBranch1...5
at the time of processing.
• The input signals dwBranch1...5 are firmly assigned to the five available actions
• Input signal dwBranch1 determines the branch for action 1,
• Input signal dwBranch2 determines the branch for action 2, etc.
• Example: When the input signal dwBranch2 has the value "15" at the time of processing the ac-
tion no. 2, it is branched to the step which is entered in the parameter "Sequence step at branch
15" for action no. 2 (C04554/2).
Action call (entry in the sequence table)
with action number xxx = 001 ... 005
Parameter
The available actions 1 ... 5 are indicated via the subcodes 1 ... 5.
Parameter Possible settings Information
C04540/1...5 Sequence step at branch value 1
• Step which is executed next when
input dwBranch1...5 = "1".
0 Branching is deactivated.
(The next step in the sequence table
is processed.)
1...100 Step 1 ... 100
C04541/1...5 See possible settings for C04540. Sequence step at branch value 2
C04542/1...5 Sequence step at branch value 3
C04543/1...5 Sequence step at branch value 4
C04544/1...5 Sequence step at branch value 5
C04545/1...5 Sequence step at branch value 6
C04546/1...5 Sequence step at branch value 7
C04547/1...5 Sequence step at branch value 8
C04548/1...5 Sequence step at branch value 9
C04549/1...5 Sequence step at branch value 10
C04550/1...5 Sequence step at branch value 11
C04551/1...5 Sequence step at branch value 12
C04552/1...5 Sequence step at branch value 13
C04553/1...5 Sequence step at branch value 14
C04554/1...5 Sequence step at branch value 15
C04555/1...5 Sequence step at branch value 16
C04556/1...5 Sequence step at branch value 17
C04557/1...5 Sequence step at branch value 18
C04558/1...5 Sequence step at branch value 19
C04559/1...5 Sequence step at branch value 20
1
n
2
4 x x x
