5 Function blocks
5.139 L_SdSpeedFilter - speed signal delay
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Parameter
5.139.1 Monitoring for counter overflow
This function extension will be available from library V2.02!
If the machine parameters transferred to the FB via the AxisData input are changed afterwards (e.g.
the gearbox factors), this may cause a counter overflow when the speed value defined via C04290
is converted from the real unit to the internal unit.
The FB causes a corresponding error message in case of an internal counter overflow due to a chan-
ged measuring system:
Parameter Possible settings Information
C04290 0.0000 Unit/s 214000.0000 Compensating speed
• For compensating the phase diffe-
rences.
• Initialisation: 0.0010 unit/s
C04291 0.000 s 60.000 Filter time constant
• Initialisation: 0.003 s
C04292
As of library V02.02.xx.xx
String of digits Speed unit
• Read only
C04293
As of library V02.02.xx.xx
-214748.3647 Unit/t 214748.3647 Reference speed
• Read only
• For input orientation for speed
entries.
C04294 -214748.3647 Unit/t 214748.3647 Speed at the output
• Read only
• Calculated from the speed signal
dnSpeedOut_s.
C04295 -214748.3647 Unit/t 214748.3647 Speed at the input
• Read only
• Calculated from the speed signal
dnSpeedIn_s.
C04299 Filter is enabled
• Read only
0 Filter is not active
1 Filter is active
Error number Error message in the logbook Response
61603852 0x3AC000C L_SdSpeedFilter:int.speed overflow (LS_DriveInterface) Error
61603980 0x3AC008C L_SdSpeedFilter:int.speed overflow (L_SdSetAxisData) Error
