4.12 All function blocks [A-Z]
Function block Function From library
L_CamClutchPos Clutch (path-controlled)
• Clutch in or declutch a master position via a fifth
order polynomial in a path-controlled manner.
LenzeCam V01.00.xx.xx
L_CamContactor Cam group with switch-on and switch-off dynamisa-
tion
LenzeCam V01.00.xx.xx
L_CamCurve Curve interpolation for characteristics LenzeCam V01.00.xx.xx
L_CamGetAxisData Reading out machine parameters from cam data LenzeCam V01.00.xx.xx
L_CamPosMarker Reading out position marks from cam data LenzeCam V01.00.xx.xx
L_CamProfiler Curve interpolation for motion profiles LenzeCam V01.00.xx.xx
L_CamSetContDataPDO Contactor data selection via inputs/PDOs
• The inputs can be connected, for instance, to a
corresponding port block to accept contactor data
from a master control via process data objects
(PDOs).
LenzeCam V01.02.xx.xx
L_CamSetContDataSDO Contactor data selection via codes/SDOs
• The codes can be written, for instance, via para-
meter data objects (SDOs) by a master control.
LenzeCam V01.02.xx.xx
L_CamStretchAbs Stretch/compress position (absolute)
• Simple absolute stretching and compression of a
position in the limited traversing range.
LenzeCam V01.00.xx.xx
L_CamStretchFeed Stretch/compress position (relative)
• Relative stretching and compression of a position
in the "Modulo" or "Unlimited" traversing range.
LenzeCam V01.00.xx.xx
L_CamSyncIn Synchronous/oversynchronous clutch-in
• Synchronising a tool (drive) to a running material
(relative master speed).
LenzeCam V01.01.xx.xx
L_Dc2BytesToWord Type converter
• BYTE (2 x)  WORD
LenzeDataConversion
V01.00.xx.xx
L_Dc2WordsToDWord Type converter
• WORD (2 x)  DWORD
LenzeDataConversion
V01.00.xx.xx
L_Dc4BytesToDWord Type converter
• BYTE (4 x)  DWORD
LenzeDataConversion
V01.00.xx.xx
L_DcBitShift Bit shift operation LenzeDataConversion
V01.00.xx.xx
L_DcBitShiftByte Bit shift operation LenzeDataConversion
V02.02.xx.xx
L_DcBitShiftDWord Bit shift operation LenzeDataConversion
V02.02.xx.xx
L_DcBitShiftInt Bit shift operation LenzeDataConversion
V02.02.xx.xx
L_DcBitShiftWord Bit shift operation LenzeDataConversion
V02.02.xx.xx
L_DcBitsToByte Bit multiplexer
• BOOL (8 x)  BYTE
LenzeDataConversion
V01.00.xx.xx
L_DcBitsToDWord Bit multiplexer
• BOOL (32 x)  DWORD
LenzeDataConversion
V01.00.xx.xx
L_DcBitsToWord Bit multiplexer
• BOOL (16 x)  WORD
LenzeDataConversion
V01.00.xx.xx
L_DcByteBitand Bit-by-bit AND operation of two BYTE values LenzeDataConversion
V02.02.xx.xx
L_DcByteBitor Bit-by-bit OR operation of two BYTE values LenzeDataConversion
V02.02.xx.xx
L_DcByteBitxor Bit-by-bit EXCLUSIVE-OR operation of two BYTE va-
lues
LenzeDataConversion
V02.02.xx.xx
