5 Function blocks
5.97 L_LdToolControl - setpoint conditioning
362
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Parameter
dnTpDifference_p
DINT
Difference between dnTpPos_p and the position measured after detecting a touch
probe in [inc].
dnDifference_p
DINT
Current difference between dnTpPos_p and the position measured after detecting a
touch probe in [inc].
• C05153 indicates the deviation in the real unit of the machine.
Parameter Possible settings Information
C05142 -2147483647 2147483647 Status
• Display of the bit-coded output si-
gnal dnState.
C05143/1
As of library V02.02.xx.xx
String of digits Position unit
• Read only
C05143/2
As of library V02.02.xx.xx
String of digits Speed unit
• Read only
C05144
As of library V02.02.xx.xx
-214748.3647 Unit/t 214748.3647 Reference speed
• Read only
• For input orientation for speed
entries.
C05147 -2147483647 Unit/t 2147483647 Correction speed at the input
• Read only
• Calculated from the speed signal
dnTpMakeUpLeeway_s.
C05148 -2147483647 Unit/t 2147483647 Speed at the input
• Read only
• Calculated from the speed signal
dnSetSpeedIn_s.
C05149 -2147483647 Unit/t 2147483647 Speed at the output
• Read only
• Calculated from the speed signal
dnSpeedOut_s.
C05150 -214748.3647 Unit 214748.3647 Set position at the output
• Display of the output signal
dnSetPosCycle_p in the real unit of
the machine.
C05151 -214748.3647 Unit 214748.3647 Actual position at the output
• Display of the output signal
dnActPosCycle_p in the real unit of
the machine.
C05152 -214748.3647 Unit 214748.3647 Following error
• Display of the output signal
dnFollowError_p in the real unit of
the machine.
C05153 -214748.3647 Unit 214748.3647 Measured TP deviation
• Display of the output signal
dnDifference_p in the real unit of
the machine.
C05154 -214748.3647 Unit 214748.3647 Measured cycle
• Display of the output signal
dnTpTpDistance_p in the real unit
of the machine.
C05155 -214748.3647 Unit 214748.3647 TP set position at the input
• Display of the dnTpPos_p input si-
gnal in the real unit of the machi-
ne.
Identifier/data type Value/meaning
