5 Function blocks
5.189 L_TbNormalize - signal scaling with limitation
608
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.189 L_TbNormalize - signal scaling with limitation
This FB scales any signal to a parameterisable reference variable.
Inputs
Outputs
Parameter
Function
Function library: LenzeToolbox
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
dnIn
DINT
Input signal
Identifier/data type Value/meaning
dnOut_n
DINT
Scaled output signal
• Internally limited to ±200 %
bLimitActive
BOOL
Output signal within the limitation
TRUE The output signal dnOut_n is limited.
Parameter Possible settings Information
C04035 -2147483647 2147483647 Reference variable
• Setting "0" is not possible.
• Initialisation: 1073741824
GQ2XWBQ
E/LPLW$FWLYH
GQ,Q
/B7E1RUPDOL]H
&
dnOut_n
dnIn
C04035
-------------------- 100 % ⋅
=
