5 Function blocks
5.86 L_LdConvAxisV - speed ratio
316
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Parameter
Parameter Possible settings Information
C05160 Coupling measuring systems X and Y
0 Coupling via feed constants Lenze setting
1 Coupling via cycles
2 Free coupling
C05161/1 0 Unit 214748.3647 Cycle X
• Read only
C05161/2 0 Unit 214748.3647 Cycle Y
• Read only
C05162/1 0.0000 214748.3647 Coupling factor X
• Initialisation: 0.0000
C05162/2 0.0000 214748.3647 Coupling factor Y
• Initialisation: 0.0000
C05163/1 String of digits User-defined unit X
• Read only
C05163/2 String of digits User-defined unit Y
• Read only
C05165/1 -214748.3647 Unit/t 214748.3647 Speed X at the input
• Read only
• Calculated from the speed signal
dnSpeedIn_s.
C05165/2 -214748.3647 Unit/t 214748.3647 Speed Y at the output
• Read only
• Calculated from the speed signal
dnSpeedOut_s.
C05169 -2147483647 2147483647 Status
• Display of the bit-coded output si-
gnal dnState.
