5 Function blocks
5.11 L_CamSyncIn - synchronous/oversynchronous clutch-in
188
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C05606/1 -214748.3647 Unit 214748.3647 Sensor position
• Display of the dnTpPos_p input si-
gnal in the real unit of the machi-
ne.
C05606/2 -214748.3647 Unit 214748.3647 Clutch-in position
• Display of the dnOpenPos_p input
signal in the real unit of the ma-
chine.
C05606/3 -214748.3647 Unit 214748.3647 Synchronous position
• Display of the dnSyncPos_p input
signal in the real unit of the ma-
chine.
C05607 -214748.3647 Unit 214748.3647 Output position
• Display of the dnPosOut_p output
signal in the real unit of the ma-
chine.
C05608 -214748.3647 Unit/t 214748.3647 Output speed
• Display of the dnSpeedOut_s out-
put signal in the real unit of the
machine.
C05609 Error messages: Status (bit coded)
• Bits that are not itemised are re-
served for future extensions.
• Bit 31 is the default setting if one
or more other error bits (bit 16 ...
30) are set.
bits18 Clutch-in not possible
Bit 19 Resulting acceleration too high
bits23 Invalid axis data structure
bits31 General error
Parameter Possible settings Information
