5.140 L_SdSpeedSet - setpoint ramp generator
526
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C04202 0.000 s 1000.000 Basic acceleration time
• Initialisation: 1.000 s
C04203 0.000 s 1000.000 Basic deceleration time
• Initialisation: 1.000 s
C04204 0.000 s 10.000 Basic S-ramp time
• Initialisation: 0.100 s
C04207 Polarity bStop input
0 HIGH active
1 LOW active
C04208 0.00 % 100.00 Tolerance setpoint reached
• Initialisation: 1.00 %
C04212/1...15 0.000 s 1000.000 Acceleration time 1 ... 15
• Initialisation: 0.000 s
C04213/1...15 0.000 s 1000.000 Deceleration time 1 ... 15
• Initialisation: 0.000 s
C04214/1...15 0.000 s 1000.000 S-ramp time 1 ... 15
• Initialisation: 0.000 s
C04215 0 15 Active ramp parameters
• Read only
C04220 Profile mode
• Read only
0 Profile generation with linear ramps
• Relating to the reference speed
(C00011)
1 Profile generation with jerk limitati-
on (S ramps)
10 Profile generation with linear ramps
• Relating to the reference speed
(C00011)
• In case of edge change at the
bStop input with regard to the
current setpoint (constant time).
• The setpoint applied to the input
dnExtSpeedSetpoint_n is adopted
as starting value.
C04221 -200.00 % 200.00 Setpoint at the input
• Display of the
dnSpeedSetpointIn_n input signal.
C04222 -200.00 % 200.00 Target setpoint
• Display of the dnTargetSetpoint_n
output signal
C04223 -200.00 % 200.00 Setpoint at the output
• Display of the
dnSpeedSetpointOut_noutput sig-
nal.
C04224 Status "Target setpoint reached"
• Display of the
bSetpointOutInTarget output sig-
nal.
0 Target setpoint not yet reached
1 Target setpoint reached
C04225 0.000 rpm 50000.000 Load reference speed
• Read only
C04226 0.000 rpm 50000.000 Setpoint speed - load
• Read only
C04227 0.0000 Unit/t 214000.0000 Reference speed
• Read only
Parameter Possible settings Information
