3 Working with the FB editor
3.2 User interface
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.2.2 Toolbar
The FB Editor is provided with an individual toolbar in the upper position which in the following text
is called FB Editor toolbar.
• Click an icon to execute the corresponding function.
Icons/functions in the "Viewer" mode
Additional icons/functions in the activated FB Editor
Icon Function
Start online monitoring
(as of »Engineer« V2.10)
Interrupt online monitoring
(as of »Engineer« V2.10)
Stop online monitoring
(as of »Engineer« V2.10)
Enlarge view of interconnection
Reduce view of interconnection
Enlarge cutout of interconnection
Show total interconnection in the drawing area
Show FB type names (instead of FB instance names)
Show print view
Printing the interconnection ( 92)
Search function ( 42)
Configuring the exception handling ( 84)
(as of »Engineer« V2.10)
Icon Function
Insert function block or system block
 Inserting a function block ( 53)
 Inserting a system block ( 56)
Inserting a port block ( 58)
Creating/inserting a variable ( 59)
Configuring/inserting a user code ( 62)
Compiling interconnection ( 86)
