5.58 L_DcWordBitxor - bit combination
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.58 L_DcWordBitxor - bit combination
This FB carries out a bit-by-bit EXCLUSIVE OR operation of two input values of "WORD" type and also
outputs the results as "WORD".
Inputs
Outputs
Function
Example
Function library: LenzeDataConversion FB is available as of library V02.02!
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
wIn1
WORD
Value 1 for bit-by-bit EXCLUSIVE OR combination
wIn2
WORD
Value 2 for bit-by-bit EXCLUSIVE OR combination
Identifier/data type Value/meaning
wOut
WORD
Result of the bit-by-bit EXCLUSIVE OR operation of wIn1 and wIn2
wIn1 - bit n wIn2 - bit n wOut - bit n
0 0 0
0 1 1
1 0 1
1 1 0
wIn1 = 0001011000101000
wIn2 = 0100100001111000
----------------
wOut = 0101111001010000
/B'F:RUG%LW[RU
Z,Q
Z,Q
Z2XW
%LW %LW
