Function blocks

5.77

L_DevSMStateDecoder - status signals from the safety module

284

Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

5.77

L_DevSMStateDecoder - status signals from the safety module

The SM3xx safety module uses the bit-coded status signal SM_dnState of the

SB LS_SafetyModuleInterface to transmit the status of the safety functions to the application. The

FB decodes the status signal into individual boolean status signals for further use in the FB intercon-

nection.

• The FB functionality corresponds to a converter "DINTBOOL", but the boolean outputs of this

FB have the same names according to their meaning.

Inputs

Function library:

LenzeDevice9400

FB is available as of library V02.00.xx.xx!

FB may only be used for firmware as of V1.50!

Runtime software licence:



Motion Control HighLevel



Motion Control TopLevel

Identifier/data type

Information/possible settings

dnState

DINT

Input for the bit-coded status signal from the safety module.

• Connect this input with the output SM_dnState of the

SB LS_SafetyModuleInterface.

/B'HY606WDWH'HFRGHU

GQ6WDWH

E6DIH7RUTXH2II

E(UURU&ODVV672

E(UURU&ODVV66

E6DIHO\/LPLWHG6SHHG2EVHUYHG

E6DIH'LUHFWLRQ3RV2EVHUYHG

E6DIH'LUHFWLRQ1HJ2EVHUYHG

E(UURU

60[[VWDWH
