Table of attributes
666
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C04306
Speed unit
20269
4F2D
S
1
VISIBLE_STRING
1
C04307
Reference speed
20268
4F2C
S
1
INTEGER_32
10000
C04360
Upper limit value
20215
4EF7
A
2
INTEGER_32
100
C04361
Acceleration time
20214
4EF6
A
2
INTEGER_32
1000
C04362
Deactivation function
20213
4EF5
S
1
INTEGER_32
1
C04363
Initialisation function
20212
4EF4
S
1
INTEGER_32
1
C04368
Output setpoint
20207
4EEF
S
1
INTEGER_32
100
C04369
Status
20206
4EEE
S
1
INTEGER_32
1
C04312
Unit
20263
4F27
S
1
VISIBLE_STRING
1
C04375
Acceleration / deceleration time
20200
4EE8
S
1
INTEGER_32
1000
C04376
Gain of red. system deviation
20199
4EE7
S
1
INTEGER_32
100
C04377
Field of red. system deviation
20198
4EE6
S
1
INTEGER_32
100
C04378
Controller gain
20197
4EE5
S
1
INTEGER_32
10000
C04379
Controller reset time
20196
4EE4
S
1
INTEGER_32
1000
C04380
Controller rate time
20195
4EE3
S
1
INTEGER_32
1000
C04381
Positive output limit value
20194
4EE2
S
1
INTEGER_32
100
C04382
Negative output limit value
20193
4EE1
S
1
INTEGER_32
100
C04383
Filter time
20192
4EE0
S
1
INTEGER_32
1000
C04384
Characteristic - controller adaptation
20191
4EDF
A
5
INTEGER_32
100
C04385
Characteristic - controller adaptation
y(x1)
20190
4EDE
A
5
INTEGER_32
100
C04386
Ramp function generator deceleration
time
20189
4EDD
S
1
INTEGER_32
1000
C04388
Process setpoint
20187
4EDB
A
9
INTEGER_32
100
C04389
Load actual value
20186
4EDA
A
4
INTEGER_32
1
C04340
Acceleration time/deceleration time
20235
4F0B
S
1
UNSIGNED_32
1000
C04341
S-ramp time
20234
4F0A
S
1
UNSIGNED_32
1000
C04342
Setpoint at the input
20233
4F09
S
1
INTEGER_32
100
C04343
Setpoint at the output
20232
4F08
S
1
INTEGER_32
100
C04330
Signal unit
20245
4F15
S
1
VISIBLE_STRING
1
C04331
Reference value
20244
4F14
S
1
UNSIGNED_32
10000
C04332
Acceleration / deceleration time
20243
4F13
A
2
UNSIGNED_32
1000
C04333
S-ramp time for acceleration/decele-
ration
20242
4F12
A
2
UNSIGNED_32
1000
C04336
Setpoint at the input/output
20239
4F0F
A
2
INTEGER_32
10000
C04240
Gearbox factor numerator
20335
4F6F
S
1
INTEGER_32
1
C04241
Gearbox factor denominator
20334
4F6E
S
1
INTEGER_32
1
C04242
Feed constant
20333
4F6D
S
1
INTEGER_32
10000
C04243
Unit
20332
4F6C
S
1
UNSIGNED_32
1
C04244
User-defined unit
20331
4F6B
S
1
VISIBLE_STRING
1
C04245
Time unit
20330
4F6A
S
1
UNSIGNED_32
1
C04246
Axis name
20329
4F69
A
2
VISIBLE_STRING
1
C04248
Cycle
20327
4F67
S
1
INTEGER_32
10000
C04249
Resolution of an encoder revolution
20326
4F66
S
1
UNSIGNED_32
1
C04251
Reference speed
20324
4F64
S
1
INTEGER_32
10000
Code
Name
Index
Data
Access
dec
hex
DS
DA
DT
Factor
R
W
CINH
