5 Function blocks
5.106 L_PosGetTableAcc - acceleration table
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Outputs
Identifier/data type Value/meaning
dnState
DINT
Status (bit coded)
Bit15 Error is active (collective message).
bit16 dwAccTableNumber1 is not within the valid range.
bits17 dwAccTableNumber2 is not within the valid range.
bits18 dwAccTableNumber3 is not within the valid range.
Bit 19 dwAccTableNumber4 is not within the valid range.
bits20 dwAccTableNumber5 is not within the valid range.
bits27 Error: Invalid FB instance data.
dnAcceleration1...5_x
DINT
Acceleration value parameterised at table position or in profile number
dwAccTableNumber1...5.
• Output as speed variation/time
• Scaling: 2 22 ≡ 15000000 [rpm/s]
