Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05

585

5

Function blocks

5.169

L_TbDiv - division

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

5.169

L_TbDiv - division

This FB carries out a division with remainder.

Inputs

Outputs

Function library:

LenzeToolbox

Runtime software licence:

Motion Control HighLevel

Motion Control TopLevel

Identifier/data type

Information/possible settings

dnNumerator

DINT

Dividend (numerator)

dnDenominator

DINT

Divisor (denominator)

Identifier/data type

Value/meaning

dnOut

DINT

Quotient value (integer result of division)

dnResidualValue

DINT

Remainder

GQ2XW

GQ1XPHUDWRU

GQ'HQRPLQDWRU

/B7E'LY

E

D

GQ5HVLGXDO9DOXH
