5.25 L_DcByteBitxor - bit combination
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.25 L_DcByteBitxor - bit combination
This FB carries out a bit-by-bit EXCLUSIVE/OR operation of two input values of "BYTE" type and also
outputs the results as "BYTE".
Inputs
Outputs
Function
Example
Function library: LenzeDataConversion FB is available as of library V02.02!
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
byIn1
BYTE
Value 1 for bit-by-bit EXCLUSIVE OR combination
byIn2
BYTE
Value 2 for bit-by-bit EXCLUSIVE OR combination
Identifier/data type Value/meaning
byOut
BYTE
Result of the bit-by-bit EXCLUSIVE/OR operation of byIn1 and byIn2
byIn1 - bit n byIn2 - bit n byOut - bit n
0 0 0
0 1 1
1 0 1
1 1 0
byIn1 = 00101001
byIn2 = 01111000
--------
byOut = 01010001
