5 Function blocks
5.171 L_TbFlipFlopD - D flipflop
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.171 L_TbFlipFlopD - D flipflop
This FB is created as a D flipflop and can be used to evaluate and save digital signal edges.
• With each rising edge at the clock input bClk the current status of the input bD is saved internal-
ly and output to the output bOut.
• The flipflop can be reset by a TRUE signal at the reset input bR which has the highest priority.
Inputs
Outputs
Function library: LenzeToolbox
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
BD
BOOL
Input
bClk
BOOL
Saving of input value
FALSETRUE The input value bD is saved internally and output to bOut until a new
value is saved or the flipflop is reset via bR.
bR
BOOL
Flipflop reset
• This input has the highest priority.
TRUE The output bOut is reset to FALSE.
Identifier/data type Value/meaning
bQ
BOOL
State of the D flipflop
bQn
BOOL
Inverted state of the D flipflop (≡ bQ)
E&ON
E5
E'
/B7E)OLS)ORS'
&/5
'
E4
E4Q
4
4
