4 Short overview
4.12 All function blocks [A-Z]
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
L_DcSetBitOfByte Bit operation
• Set a single bit to "1".
LenzeDataConversion
V01.00.xx.xx
L_DcSetBitOfDWord Bit operation
• Set a single bit to "1".
LenzeDataConversion
V01.00.xx.xx
L_DcSetBitOfWord Bit operation
• Set a single bit to "1".
LenzeDataConversion
V01.00.xx.xx
L_DcSpeed_sToNorm_n Signal converter
• 32-bit speed signal  32-bit signal (scaled)
LenzeDataConversion
V01.00.xx.xx
L_DcSpeed_sToSpeed_v Signal converter
• 32-bit speed signal  16-bit speed signal
LenzeDataConversion
V01.00.xx.xx
L_DcSpeed_vToSpeed_s Signal converter
• 16-bit speed signal  32-bit speed signal
LenzeDataConversion
V01.00.xx.xx
L_DcWordBitand Bit-by-bit AND operation of two WORD values LenzeDataConversion
V02.02.xx.xx
L_DcWordBitor Bit-by-bit OR operation of two WORD values LenzeDataConversion
V02.02.xx.xx
L_DcWordBitxor Bit-by-bit EXCLUSIVE-OR operation of two WORD va-
lues
LenzeDataConversion
V02.02.xx.xx
L_DcWordTo2Bytes Type converter
• WORD  BYTE (2 x)
LenzeDataConversion
V01.00.xx.xx
L_DcWordToBits Bit demultiplexer
• WORD  BOOL (16 x)
LenzeDataConversion
V01.00.xx.xx
L_DcWordToBits Bit demultiplexer
• WORD  BOOL (16 x)
LenzeDataConversion
V01.00.xx.xx
L_DcWordToByte Type converter
• WORD  BYTE
LenzeDataConversion
V01.00.xx.xx
L_DcWordToDWord Type converter
• WORD  DWORD
LenzeDataConversion
V01.00.xx.xx
L_DcWordToInt Type converter
• WORD  INT
LenzeDataConversion
V01.00.xx.xx
L_DevApplErr Error tripping
• The FB can trip up to 8 different application mes-
sages out of the application.
• Error ID and error response as well as the module
ID can be set via parameters.
LenzeDevice9400
V01.00.xx.xx
L_DevApplErrFix Error tripping
• The FB can trip up to 8 different application mes-
sages out of the application.
• Error ID and error response as well as the module
ID can be set via FB inputs.
LenzeDevice9400
V02.00.xx.xx
L_DevBrakeStateDecoder Status signals of the basic function "Brake control"
(SB LS_Brake)
LenzeDevice9400
V01.00.xx.xx
L_DevDriveInterfaceStateDecoder Status signals of the drive interface
(SB LS_DriveInterface)
LenzeDevice9400
V01.00.xx.xx
L_DevHomingStateDecoder Status signals of the basic function "Homing"
(SB LS_Homing)
LenzeDevice9400
V01.00.xx.xx
L_DevLimiterStateDecoder Status signals of the basic function "Limiter"
(SB LS_Limiter)
LenzeDevice9400
V01.00.xx.xx
L_DevManualJogStateDecoder Status signals of the basic function "Manual jog"
(SB LS_ManualJog)
LenzeDevice9400
V01.00.xx.xx
Function block Function From library
