3 Working with the FB editor
3.4 Creating/reconfiguring the interconnection
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Context menu for the function block
If you right-click on the header of a function block, a context menu opens via which you can execute
the following functions in addition to the general processing functions (Copy, Insert, Delete):
Related topics:
 Deleting objects that are no longer required ( 70)
 Changing connector visibilities ( 72)
 Arranging objects in the drawing area ( 73)
 Creating/deleting connections ( 74)
 Changing the processing order ( 81)
Command Function
Connector visibilities... Define visible inputs and outputs for function blocks.
 Changing connector visibilities ( 72)
Order... Change order index of the function block.
 Changing the processing order ( 81)
Parameter... Open parameter list or parameterisation dialog of the function block.
• Only if function block is parameterisable.
Properties Define function block properties.
Display type names Show FB type names (instead of FB instance names).
