5 Function blocks
5.65 L_DevApplErrFix - error tripping
254
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Inputs
Outputs
Identifier/data type Information/possible settings
bSetError1
BOOL
Input for error message 1 (highest priority)
FALSETRUE Error condition 1 is met and the parameterised application error
message is output by the operating system.
FALSE Error condition 1 is no longer met.
... ...
bSetError8
BOOL
Input for error message 8 (lowest priority)
FALSETRUE Error condition 8 is met and the parameterised application error
message is output by the operating system.
FALSE Error condition 8 is no longer met.
dwErrorId1...8
DWORD
Error ID (0 ... 65535) for error message 1 ... 8
dwReactionId1...8
DWORD
Error response for error message 1 ... 8
0 None
1 Error
2 Trouble
3 Quick stop by trouble
4 Warning locked
5 Warning
6 Information
dwModulId
DWORD
Module ID (980 ... 990)
Identifier/data type Value/meaning
dnState
DINT
Display of the error message last transmitted to the operating system.
1 Error message 1 is active.
2 Error message 2 is active.
4 Error message 3 is active.
8 Error message 4 is active.
16 Error message 5 is active.
32 Error message 6 is active.
64 Error message 7 is active.
128 Error message 8 is active.
dnErrorNo
DINT
Current error number
