5 Function blocks
5.46 L_DcNorm_nToSpeed_s - signal converter
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.46 L_DcNorm_nToSpeed_s - signal converter
This FB uses the transmitted machine parameters and converts a scaled 32-bit signal into a 32-bit
speed signal.
Inputs
Outputs
Function library: LenzeDataConversion
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
dnIn_n
DINT
Input signal in [%]
• 100 % ≡ 2 30 ≡ 1073741824
AxisData Machine parameters
• For accepting the machine parameters of the drive/motor, connect this input
with the output DI_AxisData of the SB LS_DriveInterface.
• The machine parameters of a master drive can be displayed with the
FB L_SdSetAxisData . In this case, the FB output AxisData must be connected to
this input. ( 510)
Identifier/data type Value/meaning
dnOut_s
DINT
Output signal in [rpm]
• 15000 rpm ≡ 2 26 ≡ 67108864
GQ2XWBV GQ,QBQ
/B'F1RUPBQ7R6SHHGBV
$[LV'DWD
>@ %LW >USP@ %LW
