5.204 L_TbXor - XOR with 2 inputs
This FB carries out a logic EXCLUSIVE OR operation of binary signals.
Inputs
Outputs
Function
Function library: LenzeToolbox
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
bIn1
BOOL
Input 1
bIn2
BOOL
Input 2
Identifier/data type Value/meaning
bOut
BOOL
Result of the exclusive OR operation
bIn2 bIn1 bOut
FALSE FALSE FALSE
FALSE TRUE TRUE
TRUE FALSE TRUE
TRUE TRUE FALSE
