5 Function blocks
5.180 L_TbMul_n - scaled multiplication with limitation
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.180 L_TbMul_n - scaled multiplication with limitation
This FB carries out a multiplication. The multiplicand (2. factor) must be specified as a scaled signal
[%].
• The value output to output dnOut is internally limited to ±2 31 -1.
• The bLimitActive output displays if a limitation is active.
Inputs
Outputs
Function library: LenzeToolbox
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
dnIn1
DINT
Multiplier (1st factor)
dnIn2_n
DINT
Multiplicand (2nd factor)
• Scaling: 100 % ≡ 2 30 ≡ 1073741824
Identifier/data type Value/meaning
dnOut
DINT
Product value (result of the multiplication)
• Internally limited to ±2 31 -1
bLimitActive
BOOL
Status signal "Limitation active"
TRUE The output signal is limited.
GQ2XW
E/LPLW$FWLYH
GQ,Q
GQ,QBQ D
E
/B7E0XOBQ
