5 Function blocks
5.84 L_LdClutchAxisP - virtual clutch for synchronism
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.84 L_LdClutchAxisP - virtual clutch for synchronism
This FB provides the "Time-controlled virtual clutch" function with position reference for the "Syn-
chronism" application.
Inputs
Function library: LenzeLineDrive Do not use FB for new developments!
Replacement by L_EsClutchPos .
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
dnSetPosition_p
DINT
Selection of an external master position in [inc]
• E.g. by an absolute value encoder or a virtual master.
• The external master position must be within the cycle.
• C05078 indicates the position of the master shaft in the real unit of the machine.
dnActPosition_p
DINT
Internal master position of the clutch function in [inc]
• The internal master position must be within the cycle.
• C05077 indicates the master position in the real unit of the machine.
• For a master value clutch, connect this input with the output dnPosOut_p of this
FB.
dnOpenPosition_p
DINT
Selection of the stop position after declutch or selection of the starting position
when engaging the master shaft in [inc].
• The stop position/starting position must be within the cycle.
• C05076 indicates the stop position in the real unit of the machine.
bEnable
BOOL
Activate the clutch function
• This input has the highest priority.
FALSE Clutch function is deactivated.
• The input dnSetPosition_p connected 1:1 to the output
dnPosOut_p. No ramps are active.
TRUE Clutch function is activated.
bClose
BOOL
Control of clutch function
FALSE Open the clutch.
• The master position dnPosOut_p is positioned via the set ramp to
the stop position dnOpenPosition_p.
TRUE Close the clutch.
• The master position dnPosOut_p is synchronised via the set ramp
and follows the master shaft dnSetPosition_p after it has been
clutched in.
GQ6WDWH
E,Q7DUJHW
E2SHQ
E$FF'HF
/B/G&OXWFK$[LV3
GQ2SHQ3RVLWLRQBS
E(QDEOH
E&ORVH
E2SHQ,QVWDQW
$[LV'DWD
GQ6HW3RVLWLRQBS
GQ$FW3RVLWLRQBS
GQ3RV2XWBS
'HFOXWFK
5DPS
&OXWFK
LPPHGLDWHO\
&
&
& n
p
o n
o
p
&OXWFKLQ
&
&
&
&
&
