5 Function blocks
5.86 L_LdConvAxisV - speed ratio
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Function
This FB transforms a speed between two axes, calculating the function of an electronic gearbox. The
transformation works with remainder processing.
Operating mode 0 (unit coupling):
• In this operating mode, the FB couples both axes via the set feed constants.
• Via C05162/1 and C05162/2 the ratio of the corresponding units is set, i.e. the number of units
of the X axis that corresponds to the number of units of the Y axis.
[5-43] Formula for operating mode 0
Operating mode 1 (clock equality):
• In this operating mode the FB makes use of the set cycles. The transformation displays one cycle
of the X axis exactly in one cycle of the Y axis.
[5-44] Formula for operating mode 1
Operating mode 2 (free coupling):
• In this operating mode the set feed constants are not used for the transformation.
• Via C05162/1 and C05162/2 the revolution ratio is indicated, i.e. the number of revolutions of
the master shaft that corresponds to the number of revolutions of the tool.
[5-45] Formula for operating mode 2
Output value Input value Gearbox constant Y
Gearbox constant X
--------------------------------------------------- Feed constant X
Feed constant Y
----------------------------------------- Coupling factor Y (C05162/2)
Coupling factor X (C05162/1)
--------------------------------------------------------------------------- ⋅ ⋅ ⋅
=
Output value Input value Gearbox constant Y
Gearbox constant X
--------------------------------------------------- Feed constant X
Feed constant Y
----------------------------------------- Cycle Y
Cycle X
------------------ ⋅ ⋅ ⋅ =
Output value Input value Gearbox constant Y
Gearbox constant X
--------------------------------------------------- Coupling factor Y (C05162/2)
Coupling factor X (C05162/1)
--------------------------------------------------------------------------- ⋅ ⋅ =
