3 Working with the FB editor
3.4 Creating/reconfiguring the interconnection
80
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.4.5.4 Deleting connections that are no longer required

How to delete connection lines:
1. Select connection lines to be deleted.
• Select a single connection line by directly clicking on the connection line with the right
mouse button.
• If you click further connection lines while pressing they are added to an already
existing selection (multi-selection).
• All connection lines are highlighted in red.
2. Press .

How to delete port identifiers/flags:
1. Select the port identifiers to be deleted.
• Select a single port identifier by directly clicking on the port identifier with the left
mouse button.
• If you click further port identifiers while pressing they are added to an already
existing selection (multi-selection).
• All selected port identifiers are highlighted by a light green header.
2. Press .
Related topics:
 Deleting objects that are no longer required ( 70)
