Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
433
5 Function blocks
5.114 L_PosSequencer - sequence control
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
dwBranch3
DWORD
Input signal for action 3 of type "Variable branch"
• Display parameter: C04692/3
• If the positioning program contains the action 3 of type "Variable branch", a
branch is carried out depending on the value applied to this input.
0 Branch to the next step.
1 Branch to the step defined in C04540/3.
2 Branch to the step defined in C04541/3.
... ...
20 Branch to the step defined in C04559/3.
> 20 Branch to the next step.
dwBranch4
DWORD
Input signal for action 4 of type "Variable branch"
• Display parameter: C04692/4
• If the positioning program contains the action 4 of type "Variable branch", a
branch is carried out depending on the value applied to this input.
0 Branch to the next step.
1 Branch to the step defined in C04540/4.
2 Branch to the step defined in C04541/4.
... ...
20 Branch to the step defined in C04559/4.
> 20 Branch to the next step.
dwBranch5
DWORD
Input signal for action 5 of type "Variable branch"
• Display parameter: C04692/5
• If the positioning program contains the action 5 of type "Variable branch", a
branch is carried out depending on the value applied to this input.
0 Branch to the next step.
1 Branch to the step defined in C04540/5.
2 Branch to the step defined in C04541/5.
... ...
20 Branch to the step defined in C04559/5.
> 20 Branch to the next step.
dwDigitalInputs
DWORD
Sequencer inputs 1 ... 32 (bit coded)
• The action types "Positioning", Branching", "Waiting" and "Stand-by" have the pa-
rameter "Input for...". If this is non-zero, it describes the number of the sequencer
input where the positioning program awaits the level defined before it executes
the action.
• For the transmission of individual control signals a BOOL-to-DWORD converter
can be connected to this input.
• Display parameter: C04693/1
bits0 Sequencer input 1
bits1 Sequencer input 2
... ...
bits31 Sequencer input 32
Identifier/data type Information/possible settings
