5 Function blocks
5.12 L_Dc2BytesToWord - type converter
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.12 L_Dc2BytesToWord - type converter
This FB converts two input values of type "BYTE" into an output value of type "WORD".
Inputs
Outputs
Function library: LenzeDataConversion
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
byInput1
BYTE
Input value 1 ≡ bit 0 ... bit 7 of wOut
byInput2
BYTE
Input value 2 ≡ bit 8 ... bit 15 of wOut
Identifier/data type Value/meaning
wOut
WORD
Value of type "word" according to the transmitted input values
/B'F%\WHV7R:RUG
E\,QSXW
E\,QSXW
Z2XW
