Table of attributes
664
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C04551
Var. branch n: Jump destin. 12
20024
4E38
A
5
UNSIGNED_32
1
C04552
Var. branch n: Jump destin. 13
20023
4E37
A
5
UNSIGNED_32
1
C04553
Var. branch n: Jump destin. 14
20022
4E36
A
5
UNSIGNED_32
1
C04554
Var. branch n: Jump destin. 15
20021
4E35
A
5
UNSIGNED_32
1
C04555
Var. branch n: Jump destin. 16
20020
4E34
A
5
UNSIGNED_32
1
C04556
Var. branch n: Jump destin. 17
20019
4E33
A
5
UNSIGNED_32
1
C04557
Var. branch n: Jump destin. 18
20018
4E32
A
5
UNSIGNED_32
1
C04558
Var. branch n: Jump destin. 19
20017
4E31
A
5
UNSIGNED_32
1
C04559
Var. branch n: Jump destin. 20
20016
4E30
A
5
UNSIGNED_32
1
C04570
Wait. act. n: Comment
20005
4E25
A
25
VISIBLE_STRING
1
C04571
Wait. act. n: Waiting time
20004
4E24
A
25
UNSIGNED_32
1000
C04572
Wait. act. n: Input for "Next""
20003
4E23
A
25
UNSIGNED_32
1
C04573
Wait. act. n: Input polarity
20002
4E22
A
25
UNSIGNED_8
1
C04580
Counter set act. n: Counter no.
19995
4E1B
A
10
UNSIGNED_32
1
C04581
Counter set act. n: Starting value
19994
4E1A
A
10
INTEGER_32
1
C04582
Counter n: Current counter content
19993
4E19
A
10
INTEGER_32
1
C04590
Count. act. n: Counter no.
19985
4E11
A
25
UNSIGNED_32
1
C04591
Count. act. n: Step value
19984
4E10
A
25
INTEGER_32
1
C04592
Count. act. n: comparison value
19983
4E0F
A
25
INTEGER_32
1
C04593
Count. act. n: Jump destination
19982
4E0E
A
25
UNSIGNED_32
1
C04594
Count. act. n: Comparison op.
19981
4E0D
A
25
UNSIGNED_32
1
C04600
Stand-by act. n: Comment
19975
4E07
A
5
VISIBLE_STRING
1
C04601
Stand-by act.n: Input for "End""
19974
4E06
A
5
UNSIGNED_32
1
C04602
Stand-by act. n: Input polarity
19973
4E05
A
5
UNSIGNED_8
1
C04690
DIS: bHomingDone
19885
4DAD
A
15
UNSIGNED_8
1
C04691
DIS: dnState
19884
4DAC
S
1
INTEGER_32
1
C04692
DIS: dwBranch1
19883
4DAB
A
8
UNSIGNED_32
1
C04693
DIS: dwDigitalInputs
19882
4DAA
A
2
UNSIGNED_32
1
C04319
Unit
20256
4F20
S
1
VISIBLE_STRING
1
C04320
Rate time
20255
4F1F
S
1
INTEGER_32
1000
C04321
Position unit
20254
4F1E
S
1
VISIBLE_STRING
1
C04322
Position at the input
20253
4F1D
S
1
INTEGER_32
10000
C04323
Position at the output
20252
4F1C
S
1
INTEGER_32
10000
C04410
Gearbox factor
20165
4EC5
A
2
INTEGER_32
1
C04411
Feed constant
20164
4EC4
S
1
INTEGER_32
10000
C04412
Unit
20163
4EC3
S
1
VISIBLE_STRING
1
C04413
Time unit
20162
4EC2
S
1
VISIBLE_STRING
1
C04414
Axis name
20161
4EC1
S
1
VISIBLE_STRING
1
C04416
Cycle
20159
4EBF
S
1
INTEGER_32
10000
C04418
Resolution of an encoder revolution
20157
4EBD
S
1
UNSIGNED_32
1
C04420
Reference speed
20155
4EBB
S
1
INTEGER_32
10000
C04422
Traversing range
20153
4EB9
S
1
UNSIGNED_32
1
C04424
Resulting gearbox factor
20151
4EB7
S
1
INTEGER_32
1000
C04425
Resolution of a unit
20150
4EB6
S
1
INTEGER_32
10000
Code
Name
Index
Data
Access
dec
hex
DS
DA
DT
Factor
R
W
CINH
