5 Function blocks
5.3 L_CamCurve - curve interpolation for characteristics
150
Lenze · 9400 function library · Reference manual · DMS 6.7 EN · 08/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Outputs
Parameter
Identifier/data type Value/meaning
dnYOutput
DINT
Output value (y axis)
• C05547 indicates the output value in the real unit of the machine.
bError
BOOL
"Error" status
TRUE An error has occurred (group signal).
• For details see display parameters C05549.
XAxisData Machine parameters of the x axis (zero for characteristic)
• Via this output the machine parameters used by the FB can be easily transferred
to subsequent FBs.
YAxisData Machine parameters of the y axis (zero for characteristic)
• Via this output the machine parameters used by the FB can be easily transferred
to subsequent FBs.
Parameter Possible settings Information
C05540/1 String of digits Unit of the x axis
• Read only
C05540/2 String of digits Designation of the x axis
• Read only
C05541/1 String of digits Unit of the y axis
• Read only
C05541/2 String of digits Designation of the y axis
• Read only
C05547 -214748.3647 Unit 214748.3647 Input position
• Display of the dnXInput input sig-
nal in the real unit of the machine.
C05548 -214748.3647 Unit 214748.3647 Output position
• Display of the output signal
dnYOutput in the real unit of the
machine.
C05549 Error messages: Status (bit coded)
• Bits that are not itemised are re-
served for future extensions.
• Bit 31 is the default setting if one
or more other error bits (bit 16 ...
30) are set.
bits25 Invalid data track number
bits26 Invalid data track type
bits31 General error
