5.67 L_DevDriveInterfaceStateDecoder - status signals of the drive interface
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.67 L_DevDriveInterfaceStateDecoder - status signals of the drive interface
This FB decodes the status output signal dnState of the SB LS_DriveInterface into individual boolean
status signals for further use in the FB interconnection.
• The functionality corresponds to a converter "DINTBOOL", but the boolean outputs of this FB
have the same names according to their meaning.
Inputs
Function library: LenzeDevice9400
Runtime software licence:  Motion Control HighLevel  Motion Control TopLevel
Identifier/data type Information/possible settings
dnState
DINT
Input for the bit-coded status signal of the drive interface.
• Connect this input with the output of the same name of the
SB LS_DriveInterface.
/B'HY'ULYH,QWHUIDFH6WDWH'HFRGHU
GQ6WDWH
/6B'ULYH,QWHUIDFHVWDWH
E$FWLYH
E'RQH
E$FF'HF
E&FZ
E+RPH3RV2.
E%UDNH5HOHDVHG
E=HUR3RV
E(UURU$FWLYH
E7RUTXH)ROORZHU
E6SHHG)ROORZHU
E3RVLWLRQ)ROORZHU
E)ROORZHU$FWLYH
E3RVLWLRQLQJ$FWLYH
E+RPLQJ$FWLYH
E0DQXDO-RJ$FWLYH
E%UDNH7HVW$FWLYH
E6WDQGVWLOO$FWLYH
E6WRSSLQJ$FWLYH
E4VS$FWLYH
E'ULYH1RW5HDG\
E,QLW
E)DLO
E1RW2SHUDWLRQDO
